40 Ton 3 Axles Flat Bed Semi Trailer
40 Ton 3 Axles Flat Bed Semi Trailer
Product Description
| No. | Part Name | Composition | Specifications |
| 1 | Weight | Tare Weight | 6.5-8.5T |
| Loading Capacity | 30-60T | ||
| Axle weighT load | 13T/ 16T/ 20T | ||
| 2 | Chassis | Main beam |
Material is Q345Steel; The height of the beam is 500mm; Upper plate; 14mm; Middle plate is 8mm; Down plate is 16mm. |
| Side beam | 10#/14# /16# /18# channel steel | ||
| King Pin | 2”or 3.5”Traction Pin | ||
| Dimensions (L*W*H) | 12500mm*2500mm*1550mm | ||
| Floor | 3mm/ 4mm diamond steel plate | ||
| 3 | Suspension | Suspension type | Common mechanical or Air suspension |
| Steel Spring | 10/10/10 | ||
| 4 | Running system | Axle | 2 or 3, axles, FUWA, BPW or other optional brand |
| Wheel Rim | 8.00-20, 9.0-20, 8.25-22.5, 9.00-22.5, | ||
| Wheelbase | 7180/6680/6260+1310+1310mm | ||
| Tire | Specification: 11.00R20, 12.00R22.5 Number of Tire:8 or12 pieces |
||
| 5 | Brake system | Brake Chamber | T30/30 spring brake chamber, with big air tanks |
| Brake Valve | KTL Brand/WEBCO | ||
| Brake system | Dual Line Brake system, ABS is optional | ||
| 6 | Other | Tool box | 1 set of standard tool box |
| Light | LED light | ||
| Painting | FirsT coat of anticorrosive prime, twice coats of final paint. | ||
| Spare Tire Carriers | 2 pieces | ||
| Twist lock | 4 / 8/12 pcs | ||
| Landing gear | Heavy duty landing gear | ||
| Electronic system | 24v, 7core socket |
Packing and Shipping:
Why us?
- Since 2000, With over 17yrs experience
- Advanced equipments and rigorous quality control system
- Reliability, Safety and Economic Transport solutions
- Custom Production according to demand
- All products is fully tested before delivery
- Perfect after-sales service
- We accept 100% inspection, welcome to our factory at any time
- Competitive Price
- Fast delivery
Our Services
Pre-sale: We provide FREE consolation service, and provide an obligation free quote.
After-sale: 100% guarantee in after service. No damage to human factors, one year warranty, life-long maintenance.
Our factory to co-oriented, equipped with professional service personnel to after-sales product tracking service, free comprehensive consulting services.
FAQ
1. Are you a manufacturer ?
Yes, welcome to visit our factory at anytime.
2. How is your quality?
We guarantee the quality with our high technology, advanced equipments and rich experiences.
3. What is your MOQ?
One unit trailer or truck.We suggest two trailers one time to save the freight.
4. Can you produce according to my specification?
Definitely! We are direct manufacturer and we have strong producing capacity and R&D capacity!
