4000 liters oil tanker trailer
4000 liters oil tanker trailer
| Specifications | |
| Shape | Optional(Round or Square) |
| Dimension | 11980mm×2500mm×3800mm (adjustable as your requirements) |
| Tare weight | 9000kg |
| Total Volume | 40L |
| Tanker Body Material | 5mm or 6mm Q235 carbon steel |
| End Plate | 5mm or 6mm Q235 carbon steel |
| Manhole Cover | Carbon steel or Aluminum alloy API manhole cover. Diameter: 500mm |
| Compartments | 1-7 Optional |
| Bottom Valve | Aluminum API Pneumatic Bottom Valve |
| Discharging Valve | Diameter is 3 or 4 inches |
| Discharging Pipe | 4” rubber hose, 2 pcs, 6m/each |
| CaT Walk | Standard or optional |
| Main Beam | Welding design or Special design, connected by bolts and nuts. Material: Q345 carbon steel |
| Axle | 2 or 3 axles, BPW/FUWA/HUAJING brand |
| Landing gear | JOST(D200T) or China brand 28T(two speed) |
| King Pin | JOST 2.00 or 3.5 inch bolt-in king pin |
| Suspension | Mechanical suspension(Germany or America type) or Air suspension |
| Leaf Spring | 90(W)mm×13(Thickness)mm×10(Layer) or 100mm×12mm×12 |
| Pneumatic Braking system | WABCO RE 6 relay valve; Spring brake chamber(TKL brand); 2 pieces of 45L air tanks |
| Rim | 9.00-22.5/8.00-20/8.5-20 |
| Tire | 12R22.5, 315/80R22.5, 11.00R20, 12.00R20 |
| ABS | Optional |
| Painting | FirsT coat of anticorrosive prime, Second coats of final paints |
| Accessories | One standard tool box |
| Shipping Terms | By Bulk Cargo Carrier, RORO or 40HQ Container |
| Productio Time | Usually 15-20 days but according to the order Qty |
Our Services
Pre-sale: We provide FREE consolation service, and provide an obligation free quote.
After-sale: 100% guarantee in after service. No damage to human factors, one year warranty, life-long maintenance.
Our factory to co-oriented, equipped with professional service personnel to after-sales product tracking service, free comprehensive consulting services.
FAQ
1. Are you a manufacturer ?
Yes, welcome to visit our factory at anytime.
2. How is your quality?
We guarantee the quality with our high technology, advanced equipments and rich experiences.
3. What is your MOQ?
One unit trailer or truck.We suggest two trailers one time to save the freight.
4. Can you produce according to my specification?
Definitely! We are direct manufacturer and we have strong producing capacity and R&D capacity!
