Special trailer for heavy equipment crane load trailer
Special trailer for heavy equipment crane load trailer
| Center-line Tare Weight | 3.5T |
| Rated Capacity | 40T |
| Dimension | 15000mm+3700mm+700mm *3000mm*1750+300mm |
| Suspension | Stroke hydraulic + / - 300 mm |
| Basic module width | 3.000 mm |
| Angle of rotation axis | ±55° |
| Hydraulic system | Safety valves |
| Main beam Material | AH60,40Cr |
| Tire Size | 215/75 R 17,5 |
| Wheelbase | 1500mm |
| Alarm panel | 2 pairs |
| Flashing light | 2 pcs |
| Tool box | 1 set of standard tools |
| Diesel Power Plant | 22 KW |
| Hydraulic Pump | 30 1/ min |
| Hydraulic bolted connector | 3 pcs |
| Main Parts | 4 line-axles |
| Outside Dimension | 6000mm*3000mm*1750+300mm |
| Axles / Tires | 8 Axles / 32 Tires |
| Modules Connections | Side battle for differenT combinations. Axle units mounted on the frame by bolting |
| Standard Shaft | 3000mm long, flexible coupling ring, diameter 50 mm |
| Operating head | 2 file combination |
| Wireless Remote Control | Handheld operator panel / Transmitter - 1 piece |
| Braking system | Dual Line braking system with automatic air brake and ABS |
| Operating panel | 1 pc with leveling system |
| Tool box | 1 set of standard tools |
Our Services
Pre-sale: We provide FREE consolation service, and provide an obligation free quote.
After-sale: 100% guarantee in after service. No damage to human factors, one year warranty, life-long maintenance.
Our factory to co-oriented, equipped with professional service personnel to after-sales product tracking service, free comprehensive consulting services.
FAQ
1. Are you a manufacturer ?
Yes, welcome to visit our factory at anytime.
2. How is your quality?
We guarantee the quality with our high technology, advanced equipments and rich experiences.
3. What is your MOQ?
One unit trailer or truck.We suggest two trailers one time to save the freight.
4. Can you produce according to my specification?
Definitely! We are direct manufacturer and we have strong producing capacity and R&D capacity!
