SUV car transporter trailer
SUV car transporter trailer
| HD hydraulic lifting car carrier trailer | |
| Trailer Model | 2 Axles car/vehicle carrier semi trailer |
| Overall Dimension(mm) | 13700*2500*3900 (L*W*H) (as requirement) |
| Tare weight | 12000KG |
| Capacity | 30-60T |
| Loading Capacity | Two floors, 5-8 cars, we can design as your requirement |
| Function | Transport car or vehicles |
| Main Frame | 350mm-500 heighT I beam, Top Flange 10-14mm, Middle Flange 6-8mm; Bottom Flange 12-16mm (change by different capacity) |
| Floor | 3mm -5 thickness |
| Axle | 2 or 3 axles, 13Tor 16T per axle, FUWA or other optional brand |
| Tire | 8 or 12 sets 12R22.5 Triangle (optional) |
| King Pin | JOST brand 2" or 3.5" |
| Suspension | Mechanical suspension |
| Landing gear | 28T, manual operating, Heavy duty |
| Braking systerm | Dual line-air brake, piggyback spring on all axles; four units of |
| T30/30 spring brake chamber. four lifting hydro-cylinder. Three | |
| aircrafT jump frames. | |
| Electril system | 24v, 7core socket Led Tail lamp with turn signal, Brake lighT & reflector, side lamp etc |
| Painting | Complete Chassis sand blasting to clean rust, 1 coat of anticorrosive prime, 2 coats of final paint Color can be chosen |
| Spare Wheel Carrier | 1 set |
| Tool Box | 1 set |
Related products:
Our Services
Pre-sale: We provide FREE consolation service, and provide an obligation free quote.
After-sale: 100% guarantee in after service. No damage to human factors, one year warranty, life-long maintenance.
Our factory to co-oriented, equipped with professional service personnel to after-sales product tracking service, free comprehensive consulting services.
FAQ
1. Are you a manufacturer ?
Yes, welcome to visit our factory at anytime.
2. How is your quality?
We guarantee the quality with our high technology, advanced equipments and rich experiences.
3. What is your MOQ?
One unit trailer or truck.We suggest two trailers one time to save the freight.
4. Can you produce according to my specification?
Definitely! We are direct manufacturer and we have strong producing capacity and R&D capacity!
